The P80-U116-U78-5OT Manual 5 Spool Monoblock Directional Valve is a high-performance hydraulic valve designed for demanding applications. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is suitable for a wide range of hydraulic systems. The manual control provides precise and responsive operation, while the monoblock construction ensures durability and reliability. This valve is commonly used in material handling, construction, agriculture, and industrial vehicle applications.
| Port Size | G1/2,G3/4,M22×1.5,M27×2.0,SAE 10,1/2 NPT,3/4 NPT |
|---|---|
| Section | 1 Section,2 Section,3 Section,4 Section,5 Section,6 Section,7 Section |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Max Pressure | 315 bar (4600 psi) |
| Rated Flow | 80 L/min (21.2 US gpm) |
| Structure Type | Monoblock valve |
| Control Method | Manual |
| Inlet Port | G1/2,G3/4,M27×2.0,SAE 10,SAE 12,1/2 NPT,3/4 NPT |
**Product Features and Benefits:**
* Rated flow of 80 L/min (21.2 US gpm) for high-flow applications
* Maximum pressure of 250 bar (3600 psi) for demanding operating conditions
* Manual control for precise and responsive operation
* Monoblock construction for durability and reliability
* 5 spool design for versatile control
* Compact size for easy installation
**Applications:**
* Material handling equipment, such as forklifts and telehandlers
* Construction machinery, such as excavators, loaders, and cranes
* Agricultural equipment, such as tractors and harvesters
* Industrial vehicles, such as sweepers and waste compactors
