Eliminate Middlemen: Purchase P40-G12-G38-OT-QTW1 Valves Directly from the Factory

Max Pressure:250 bar (3600 psi)

Vendor:BXHS

Product Type:Monoblock Directional Valve

Product Series:P40 Series Monoblock Directional Valve

Productsize:22*17*12

Netweight:4.69 kg

Availability: In Stock

Description

Eliminate Middlemen: Purchase P40-G12-G38-OT-QTW1 Valves Directly from the Factory detailed image

Eliminate Middlemen: Purchase P40-G12-G38-OT-QTW1 Valves Directly from the Factory drawing image

The P40-G12-G38-OT-QTW1 is a 2-section, monoblock valve with manual control. It has a rated flow of 40 L/min and a maximum pressure of 250 bar. The operating viscosity range is 15 - 75 mm²/s and the ambient temperature range is -40°C to +80°C. The valve is suitable for use in material handling, construction, agriculture, and industrial vehicles.

Rated Flow	40 L/min (10.5 US gpm)
Max Pressure	250 bar (3600 psi)
Inlet Port	G3/8,G1/2,M18×1.5,M22×1.5,SAE 8,SAE 10,3/8 NPT,1/2 NPT
Outlet Port	G3/8,G1/2,M18×1.5,M22×1.5,SAE 8,SAE 10,3/8 NPT,1/2 NPT
Port Size	G3/8,G1/2,M18×1.5,SAE 8,SAE 10,3/8 NPT,1/2 NPT
Section	1 Section,2 Section,3 Section,4 Section,5 Section,6 Section,7 Section
Structure Type	Monoblock valve
Ambient Temperature Range	-40°C to +80°C (-40°F to +176°F)
Operating Viscosity Range	15 - 75 mm²/s (15 cSt to 75 cSt)

The P40-G12-G38-OT-QTW1 is a high-quality valve that is manufactured to the highest standards. It is made from durable materials and is designed to withstand even the most demanding applications. The valve is easy to install and maintain, and it comes with a comprehensive warranty.

As a leading manufacturer of hydraulic products, we offer a wide range of valves to choose from. We can also provide custom solutions to meet your specific needs. Contact us today to learn more about our products and services.

Eliminate Middlemen: Purchase P40-G12-G38-OT-QTW1 Valves Directly from the Factory application image
