This pneumatic 1 spool hydraulic control valve is designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. It features a monoblock structure, a rated flow of 40 L/min, and a maximum pressure of 160 bar. This valve is available at factory wholesale prices with fast shipping.
| TC-4 Series Hydraulic Control Valve Parameters | |
|---|---|
| Spool | 1 Spool |
| Control Method | Manual |
| Section | 1 Section |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Max Pressure | 160 bar (2300 psi) |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Structure Type | Monoblock valve |
This TC-4 series pneumatic 1 spool hydraulic control valve offers a reliable and efficient solution for controlling hydraulic systems. Its monoblock design ensures durability and ease of installation. With a rated flow of 40 L/min and a maximum pressure of 160 bar, it can handle demanding applications. The valve operates within a wide viscosity range of 15 to 75 mm²/s, making it suitable for various hydraulic fluids. Its temperature resistance from -40°C to +80°C ensures reliable performance in a variety of environments. This valve is ideal for use in forklifts, telehandlers, mini-excavators, midi-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, and harvesters.
