NSH-10 10 cc/rev 16 MPa (2320 psi) Hydraulic Gear Pump

Rated Pressure:16 MPa (2320 psi)

Max Pressure:20 MPa (2900 psi)

Vendor:BXHS

Product Type:Hydraulic Gear Pump

Product Series:NSH Series Hydraulic Gear Pump

Productsize:15*11.3*9

Netweight:2.50 kg

Availability: In Stock

Description

NSH-10 10 cc/rev 16 MPa (2320 psi) Hydraulic Gear Pump detailed image

NSH-10 10 cc/rev 16 MPa (2320 psi) Hydraulic Gear Pump drawing image

The NSH-10 10 cc/rev Hydraulic Gear Pump is a high-performance, durable pump designed for a wide range of applications. It features a rated pressure of 18 MPa (2610 psi), a rated speed of 2000 r/min, and a maximum speed of 4200 r/min. The pump is made of aluminium and has a square flange and an involute spline shaft type.

NSH Series Hydraulic Gear Pump Parameters
Displacement	10 cc/rev, 40 cc/rev, 50 cc/rev, 100 cc/rev
Shaft Type	X: Involute Spline
Flange Version	B-Square Flange
Material	Aluminium
Structure	External Gear Pump
Rotation	L: Left (counter-clockwise)
Max Speed	4200 r/min
Rated Speed	2000 r/min
Rated Pressure	18 MPa (2610 psi)

**Product Features and Benefits:**

* High efficiency and reliability
* Long service life
* Compact and lightweight design
* Easy to install and maintain

**Applications:**

* Construction equipment
* Material handling equipment
* Agricultural machinery
* Industrial vehicles

NSH-10 10 cc/rev 16 MPa (2320 psi) Hydraulic Gear Pump application image
